Industrial Rigging Hardware
The Critical Connection: High-strength lifting gear engineered for zero-failure performance in heavy industry.
Essential Gear for Safe Material Handling
Rigging hardware is the unsung hero of the material handling world. While cranes provide the power, the hardware provides the secure interface between the machine and the load. At Kylift, we specialize in high-tensile, forged components that adhere to the strictest international safety standards, including ASME B30.26 and EN 1677.
Whether you are performing a simple vertical lift or a complex multi-point tandem operation, the quality of your shackles, slings, and hooks determines the safety of your personnel and the integrity of your cargo.
Core Rigging Categories
Forged Shackles
The primary connector in rigging. Our shackles are drop-forged and quenched for maximum toughness.
- Types: Anchor (Bow) and Chain (D-Type) shackles.
- Pins: Screw pin, bolt type, and round pin configurations.
- Material: Carbon and Alloy steel options.
High-Strength Slings
Versatile load-bearing tools available in multiple materials to suit specific environmental needs.
- Synthetic: Lightweight polyester web and round slings.
- Wire Rope: High-durability steel rope with swaged eyes.
- Chain Slings: Multi-leg G80 chain assemblies for heat resistance.
Lifting Hooks
Engineered with safety latches to prevent accidental unhooking under load fluctuations.
- Styles: Clevis, eye-type, swivel, and self-locking hooks.
- Safety: Integrated spring-loaded heavy-duty latches.
- Certification: 100% electromagnetic crack detection tested.
Rigging Grade Comparison
For chain-based rigging, the “Grade” indicates the strength of the steel. In industrial lifting, only Grade 80 and above are permitted for overhead use.
| Feature | Grade 80 (G80) | Grade 100 (G100) | Stainless Steel (316) |
|---|---|---|---|
| Primary Use | Heavy Industrial Lifting | Extreme Loads / Lightweight Gear | Corrosive / Chemical Environments |
| Strength Ratio | Standard Performance | 25% Higher than G80 | Lower WLL than Alloy |
| Safety Factor | $4:1$ or $5:1$ | $4:1$ | $4:1$ |
| Heat Resistance | Up to 200°C (with WLL reduction) | Up to 200°C | Excellent Anti-Corrosion |
The 5-Point Rigging Inspection Checklist
Rigging hardware must be inspected before every shift. Discard equipment immediately if you observe:
- Deformation: Any visible bending, twisting, or stretching (especially in hooks and shackle pins).
- Wear: More than 10% reduction in the original dimension at any point.
- Cracks: Any surface cracks or nicks (often found via NDT testing).
- Heat Damage: Discoloration or weld spatter on high-tensile alloy components.
- Illegible Markings: If the WLL (Working Load Limit) or Grade is not clearly visible, do not use the item.
Industry Applications
Our rigging hardware is deployed across sectors where failure is not an option:
- Oil & Gas: Offshore rigging for pipe handling and platform maintenance.
- Construction: Tower crane rigging and precast concrete panel installation.
- Entertainment: Stage rigging for lighting arrays and heavy sound systems.
- Renewable Energy: Specialized slings for wind turbine blade transportation and assembly.
